LÜTFEN FİYAT SORUNUZ!
İhtiyaca özel talep üzerine edildiğinden stoklarda bulunmaz.
MALA GPR VIDEOLARI:
Mala ProEx GPR Kurulum Videosu:
ÖNEMLİ NOT: MALA ÜRÜNLERİNİN TÜRKİYE TEK YETKİLİ BAYİSİ Dedektorburada.com'dur.
Piyasada Mala markası olarak satılan ürünler yurtdışından ya 2.el ya da kaçak yollardan tedarik edildiğinden garantisi yoktur.
Ayrıca bu firma ve/veya satıcıların ürün ile ilgili eğitim vermeleri için ne yeterli bilgi ne de eğitimleri vardır.
Bilgilerinize Sunulur.
MALA GROUND EXPLORER GX450/160/80 HDR SOLUTION (Paket İçeriği)
Items included;
GX450 HDR Sielded Antenna
GX160 HDR Sielded Antenna
GX80 HDR Sielded Antenna
GX battery/GPS module
GX450 HDR Skip Plate
GX160 HDR Skip Plate
GX80 HDR Skip Plate
GX transport protection cover
Cardboard box with foam, GX450 HDR
Cardboard box with foam, GX160 HDR
Cardboard box with foam, GX80 HDR
Shipping case accessories 1
GX controller
MALA USB software and manuals package
Converter for GX controller 110/220V to 12V DC
GX battery
Powercable / com – 3.2m
GX battery Charger 12.6V H01110030 incl. EU/UK/US power cord
GX measuring wheel
MALA Rough terrain cart (RTC) incl. Encoder
Sofware (Yazılımlar):
REFLEXW 2D&3D GPR Software
MALA ObjectMapper Software
GROUND PENETRATING RADAR / JEORADAR GENEL BİLGİ:
Yeraltı Radarı veya genel adıyla Jeoradar (GPR: Ground Penetrating Radar) yöntemi, yakın yüzey araştırmalar için kullanılan yüksek frekanslı elektromanyetik prensip ile çalışan bir jeofizik yöntemdir.
Hedeflenen derinlikler için cihaza ilave antenler almak gerekir.
GPR / Yer Altı Radarları 25 Mhz ile 3000 Mhz aralığında yani çok yüksek frekanslarda çalışırlar.
Yerin yüksek çözünürlüklerde haritasının çıkarılabilmesi için cihazın yüksek frekanslarda çalışması gerekir.
Anten frekansı ne kadar yükselirse inceleme derinliği o oranda azalır.
Jeoradarın (Yer Radarı - GPR) Kullanıldığı Alanlar:
1. Arkeolojik Araştırmalarda
* Eski Medeniyetlere Ait Yapıların ve Eski Parçaların Yerlerinin Belirlenmesinde
* Arkeolojik Alan Çalışmalarında
2. Yeraltının Haritalanması
3. Köprü ve Tünel Araştırmalarında
4. Yol Araştırmalarında
5. Yapı Analizinde
6. Çevre Araştırmalarında
SATIŞ ŞARTLARI:
ÖDEME: Siparişte tamamı peşin olarak tahsil edilir.
TESLİM SÜRESİ: Siparişe müteakiben 4-6 hafta içerisinde teslim edilecektir.
GARANTİ SÜRESİ: Sevkiyat tarihinden itibaren 1 (bir) yıldır.
EĞİTİM: Ücretsizdir – Eğitim Jeofizik Mühendisleri Tarafından Arazi Ortamında Verilecektir.
GroundExplorer
MALÅ GroundExplorer (GX) is based on innovative, patent-pending MALÅ High Dynamic Range (HDR) technology and represents a leap forward in Ground Penetrating Radar.
MALÅ GroundExplorer (GX) is an integrated GPR solution with four MALÅ GX antenna options: GX80, GX160, GX450, and GX750.
Built around a fast 1.6 GHz Intel Atom processor and using a high-resolution display to present the 32-bit data, the
MALÅ GX Controller delivers excellent performance and outdoor visibility.
The easy-to-use controller has a built-in battery to simplify handling in the field.
MALÅ GX antennas feature an integrated DGPS for accurate positioning and the solution supports the use of external GPS.
MALÅ GX solutions support a wide range of distance measuring devices.
The new WiFi option enables wireless data collection, making it easier to use in confined spaces as well as in irregular landscapes.
Normal working range varies between 25-100 meters dependent on the surroundings.
ADVANTAGES:
• Ease of use
• Exceptional detection capabilities
• Outstanding signal-to-noise ratio and depth penetration
• Significantly faster data acquisition rates
• High-resolution display with excellent outdoor visibility
• Built-in battery and WiFi option removes cables, simplifies fieldwork
SYSTEM CONFIGURATION:
Every MALÅ GX solution contains two separate components: the GX Controller and the GX antenna. These are connected either through a single cable or WiFi. MALÅ GX is typically configured as either a push- or pull-system. To configure a push-system, the MALÅ GX Controller and a MALÅ GX antenna are mountedon a Rough Terrain Cart. To configure a pull-system, an encoder wheel is fitted to the mounting block on the back of the antenna. The GX Controller is then carried with the monitor holder and the antenna assembly can be pulled with a pulling handle or a strap.
GPR with exceptional range and resolution MALÅ GroundExplorer is the first commercial GPR solution available that incorporates the advantages of modern real-time sampling. Through unique HDR technology, combined with vast experience of endusers’ needs, MALÅ GroundExplorer provides an easyto-use GPR solution with exceptional detection capabilities on a rugged platform.
Typical applications:
Archaeology
Geology
Infrastructure & Construction
Geotechnical & Environmental
Military & Police
Features:
Well designed, field-rugged enclosure
Built-in DGPS
Simplified graphical user interface
In-the-field processing and
interpretation
WiFi option
All antennas meet FCC, EC and IC regulatory limits on radio emissions
TECHICAL SPECIFICATOINS - GX450 HDR ANTENNA
Technology: MALÅ Semi-Real-Time, pat. pend.
Antenna center freq.: 450 MHz
SNR: 101 dB
Significant/useful number of bits: > 16 bits
Scans/second: > 770, time window 300 nS
Survey speed: 275 [km/h] point distance 10 cm
Bandwidth: 120 %, fractional, -10 dB
Time window: 300 ns
Positioning: Built-in DGPS, external GPS (NMEA 0183 protocol), wheel encoder
Operating time: 5 h
Power supply: Interchangeable 12 V Li-Ion batt. or ext. 12 V DC source
Power consumption: 1.3 A
Acq. Mode: Wheel, time or manual
Dimensions: 430 x 360 x 180 mm
Weight: 5.5 kg
Operating temp: -20 °C to +50 °C or 0 °F to 120 °F
Environmental: IP65
TECHICAL SPECIFICATOINS - GX160 HDR ANTENNA
Technology: MALÅ Semi-Real-Time, pat. pend.
Antenna center freq.: 160 MHz
SNR: > 107 dB
Significant/useful number of bits: > 17 bits
Scans/second: > 880, time window 625 nS
Survey speed: 320 [km/h] point distance 10 cm
Bandwidth: 120 %, fractional, -10 dB
Time window: 625 ns
Positioning: Built-in DGPS, external GPS (NMEA 0183 protocol), wheel encoder
Operating time: 5 h
Power supply: Interchangeable 12 V Li-Ion batt. or ext. 12 V DC source
Power consumption: 1.3 A
Acq. Mode: Wheel, time or manual
Dimensions: 720 x 480 x 190 mm
Weight: 10.7 kg
Operating temp: -20 °C to +50 °C or 0 °F to 120 °F
Environmental: IP65
TECHICAL SPECIFICATOINS - GX80 HDR ANTENNA
Technology: MALÅ Semi-Real-Time, pat. pend.
Antenna center freq.: 80 MHz
SNR: > 114.4 dB
Significant/useful number of bits: > 19 bits
Scans/second: > 1200, time window 812 nS
Survey speed: 430 [km/h] point distance 10 cm
Bandwidth: 120 %, fractional, -10 dB
Time window: 812 ns
Positioning: Built-in DGPS, external GPS (NMEA 0183 protocol), wheel encoder
Operating time: 5 h
Power supply: Interchangeable 12 V Li-Ion batt. or ext. 12 V DC source
Power consumption: 1.3 A
Acq. Mode: Wheel, time or manual
Dimensions: 1010 x 780 x 220 mm
Weight: 24.6 kg
Operating temp: -20 °C to +50 °C or 0 °F to 120 °F
Environmental: IP65
Not: Yukarıdaki bilgi ve açıklamalar üretici firma verileridir.
